Description:
BONO ENERGIA new CTH Hot Water Heaters are designed for thermal capacity ranging from 5 to 60MWt with hot water outlet temperature up to 260°C and total operating pressure up to 65 bar. Up to 30MWt, thanks to its innovative design, CTH heaters are delivered as complete package solution.
Thanks to its compact multi-tubular water tube structure, CTH achieve all the process requirements allowing for a simple installation circuit and granting heater overall efficiency higher than 94% based on L.H.V
Descripción
Specs:
- Marca: Bono
- Modelo: CTH
- Tipo: Acuotubular
- Presión de trabajo: hasta 65 Bar
- Rango de Generación: 80 MW
Applications:
Through the years, BONO ENERGIA CTH Hot water heaters have found their main application within district heating and industrial processes where hot water (less then 120°C) was required. Within these application CTH offered a complete and reliable solution for all required process needs. In the last years, BONO ENERGIA CTH have found further applications where high process water temperature in conjunction with high pressure and flexibility are required, such as pharmaceutical and chemical process, power plant start up equipment etc. For these applications the precise temperature control, high hot water circuit pressurisation and fast thermal response are required.
More technical information http://www.autoflame.cl/wp-content/uploads/2017/05/CTHgb.pdf
